20 DIY Welding Table Plans – Do It Yourself Easily

A welding table is the first instrument for you if you want to be a professional welder or you just want to perform crafting activities in your workshop that involve welding. We have included 20 DIY welding table plans that you can DIY from your workshop.

Welding tables are always recommended because of safety and here, in this guide I’ve selected the best welding table plans that are strong and sturdy for you. Check them out and start building!

Best DIY Welding Table Plans

1. How To Build A Welding Table

1. How To Build A Welding Table

Here’s the first project on our compilation. For the materials, you will need, 1-1/4″ x 1-1/4″ x 1/8″ x 10′ angle iron (3, 4″ x 130-lb.-rated caster with brake (4), 32″ x 20″ x 1/8″ sheet metal (2), and other materials. You will also need tools like a saw and a special tool for tacking. The making process is explained in an easy way.

Click for more details

2. DIY Welding Table

2. DIY Welding Table

When making a welding table safety is very paramount since you will be working with instruments and equipment that deals with electricity. The materials needed for this project are a welding machine, MIG wire, plasma cutter, chop saw, heavy-duty magnet, and extended metal. Start by cutting the iron angle, expanded metal, and flat iron for the first take of the tabletop.

Click for more details

3. DIY Welding Table Plans

3. DIY Welding Table Plans

The structure of some welding tables can be simple. As in the case of this, it has three significant parts which are: the tabletop, the frame, and the legs. This is made from angle iron for the frame and legs, sheet metal for the tabletop, and four caster wheels for the movement.

Click for no more details

4. Low Budget Welding Table DIY

This table provides you with a sturdy surface for your welding activities. It is also a very good project to start with if you’re looking into a career or hobby in welding. Start by drawing the plan for the structure on a sheet of paper so that the building will be easier and fast.

5. Homemade Welding Table DIY

Gather the materials and tools for this project and start by assembling the tabletop. Cut the metal pieces for the tabletop, cut the pieces for the legs and join them together with a welding machine. After this, cover the surface of each piece making the tabletop with tape then, apart from paint the whole table.

6. DIY Welding Table

In making this DIY welding table, make sure you wear your protective equipment for safety. Cut all the pieces needed for the project, cut large rectangular pieces of metal and join the pieces to form the tabletop then go ahead to weld other components of the table to it.

7. DIY Easy Welding Table Build

7. DIY Easy Welding Table Build

This is made from angle brackets, square tubing wood, grinder, gloves, clamps, and caster wheels. Start by making the frame, attach the tabletop to the frame and make the equipment holder. Attach the caster wheel to the legs and you have your welding table ready.

Click for more details

8. DIY Welding Table

8. DIY Welding Table

This is made from thick mild steel, flat bar, drop saw, set square, and caster wheel. Make the frame for the table and weld the flat bar on it. Then, attach the legs and fit the caster wheel for movement. Once the table is done paint it and you’re good to go.

Click for more details

9. Metal Welding Table Plans DIY

9. Metal Welding Table Plans DIY

The materials needed for this DIY welding table are tape measure, speed square, c-clamps, standard steel angle iron, lock washer, caster wheel, and thick mild steel plate. Cut two sheets of metal and weld them together for the tabletop then weld the frame as well. Then, attach the tabletop to the frame. Attach the legs and you’re good to go.

Click for more details

10. DIY $80 Welding Table

This is made of steel metal. The structure of the table built in this project is unique in its way and besides, it is very cheap because of the price of the steel metal. Place a metal sheet plate on the ground then measure the position for the legs and mark it out. Assemble the legs on each marked out point and weld them to the metal plate.

11. How To Build A Welding Table

The awesomeness of this table can be seen from its appearance though it’s very big and heavy the weight was lifted by the four caster wheel that helps the movement. It is an amazing DIY you’ll like  to try out. Make sure when you’re making this you wear your personal protective devices like google and hand gloves.

12. DIY Ultimate Welding Table And Cart

This amazing table is a multipurpose cart; it is a welding table, it has space on it to hang equipment, and also it serves as a cart. Gather the equipment and materials needed for the table. Cut all the pieces that will make up the table and start welding them together.

Take two pieces of flat sheets of metal, drill holes around one and join it with the other as the tabletop. Lay the tabletop upside down and start mounting and joining the table legs to it.

13. DIY Portable Welding Table

13. DIY Portable Welding Table

The materials needed for this DIY wedding table include a panel saw, drill, circular saw, pneumatic stapler, screwdriver, and jigsaw. Assemble the pieces of wood and make the box frame then go ahead to attach the handles and hooks.

Click for more details

14. Adjustable Welding Table Plans

14. Adjustable Welding Table Plans

This amazing welding table is made from a cast iron fixture plate. This particular material makes it stand out from other welding tables built with steel metals. Since the cast iron fixture plate has a perforated surface you can use a machine bar stuck to set the plates unlike where you will use wire. You can download the plan for this unique and adjustable welding table from the link below.

Click for more details

15. DIY Supreme Mobile Welding Table

15. DIY Supreme Mobile Welding Table

Get an old tent trailer and disassemble it to only bear frame which serves as the base of the table. Attach square tubing to each edge of the frame as for the tabletop. Add another two square tubings in the middle of the frame then weld the tabletop on it. Then, create a shield for the wheel to prevent it from a spark.

Click for more details

16. How To Build A Welding Table From Scrap

The materials used in this DIY project are all gotten from the scrap yard. The Steel tubing is used for the legs while the plate steel is used for the tabletop. Cut the steel tubing to size and assemble them on the plate steel. Pre-drill holes on the plate and attach the legs, weld them properly to hold them in place then go ahead to give it a finishing touch.

17. How To Build A Simple Heavy Duty Welding Table

This is made from steel tubing, thick mild steel for the tabletop, chop saw, and grit sander. Cut the pieces for the legs and measure the appropriate position for it on the tabletop, Mark the point and attach the legs in their appropriate place. Cut a piece of iron then weld it to a small metal plate and attach it to the base of the leg. Repeat this for the other three legs as well.

18. DIY Welding Table With Sliding Extensions

Make a frame for the tabletop by welding four steel tubing together to form a rectangular box. Then, cut the remaining steel tubing to size and place them on the tabletop frame. Make sure the space between each of the shell tubing is even and wide enough. Then, attach the table legs and attach the caster wheels to it to make the movement easier.

19. How To Make A Low-Cost Welding Table With BBQ

19. How To Make A Low-Cost Welding Table With BBQ

This amazing welding table has wooden shelves, metal legs, and a box. It is made from welder arc, rig, and personal protective equipment. Cut a piece of wood to your preferred size of a welder table surface then, take the metals to the chop saw and cut it down to pieces. Attach the pieces of metals to the wood and secure them together with screws.

Attach two metal pieces to each side of the legs in the middle where the wood for the shelve will be placed. Fit the wood piece in the middle snugly and secure it with screws and you have two boxes in one welding table.

Click for more details

20. DIY Professional Grade Welding Table

This is made from laser-cut sheet metals and wood. Lay five pieces of wood on the ground and place a metal plate sheet on top of it. Place two crossbars on it vertically and fit another two bars in the vertical bars horizontally. Attach the side lives and clamp everything down. Once you’ve clamp them down, start welding each piece to one another. After the welding, attach the legs and the caster wheel for movement.

Conclusion

The welding tables listed above are strong, sturdy and good to use for any welding activities. However, each has a description of how you can make your own without too much stress but don’t forget to use your personal protective devices like hand gives, google and overall since you will be working with a welder arch.
